1.5″ Tri Clamp RIMS Tube Kit, SS304 with Clamps and Seals

The main function of a RIMS tube is to maintain a constant mash temperature. It is also used for step mashing and mash-out.The element end fitting is threaded with 1″ NPS threads.

When constructed, this product will measure 20″ in length.This RIMS tube kit comes with:

• (2) RIMS tubes
• (5) 1.5″ Silicone gaskets
• (5) 1.5″ Single hinge tri clamps
• (2) 1.5″ to 1/2″ hose barb adapters

Required Parts*:

• Water Heating Element
• NPS Adapter
• Temperature Controller
• Pump

*SOLDSEPARATELY*

DETERMINING TRI CLAMP SIZE

Tri Clamp sizes are determined by the outer diameter of the pipe or tubing, not the outer diameter of the flange or Tri Clamp itself. The flange of a Tri Clamp fitting typically has about a inch greater diameter than the outside diameter of the pipe. This can become especially confusing when the Tri Clamp fitting has no pipe attached to it, as is the case with adapters, For instance, a1.5″ Tri Clamp to 1/2″ hose barb adapteris not 1.5″ inches in any dimension, but the Tri Clamp end will fit any other 1.5″ Tri Clamp fitting.

If you have any doubts about what size Tri Clamp fittings your project needs, simply measure the outside diameter of the flange (dimension “B” below) and consult the chart below, or feel free tocontact us.

Pipe Outer Diameter
A

Flange Outer Diameter
B

Pipe Inner Diameter
C
